BIM - BUILDING INFORMATION TECHNOLOGY

BIM APPLICATIONS IN AEC INFOGRAPHICS

THE FIRST PHASE OF THE SECOND PROJECT REQUIRES US TO PRODUCE A REVIT MODEL OF THE SELECTED ARCHITECTURE DESIGN USING ARCHITECTURAL COMPONENTS LIKE WALLS, ROOF, STAIRS, FLOOR, CURTAIN WALLS, DOORS AND WINDOWS. WE ARE REQUIRED TO DEMONSTRATE OUR UNDERSTANDING OF MODELLING IN A REVIT BY COMPILING OUR WORK IN PROGRESS (WIP).

*KINDLY CLICK THE TITLE 'PROJECT 1 - BIM APPLICATIONS IN AEC INFOGRAPHICS' FOR THE PROJECT' 1'S BRIEF

THIS PROJECT REQUIRES US TO CONDUCT A STUDY ON THE CURRENT APPLICATIONS OF BUILDING INFORMATION MODELING (BIM) IN THE ARCHITECTURE, ENGINEERING & CONSTRUCTION (AEC) FIELD. THIS PROJECT INTENDS TO EXPOSE US TO THE VARIOUS CURRENT APPLICATIONS IN

THE AEC INDUSTRIES, THROUGH AN IN-DEPTH REVIEW OF THE LITERATURE. THE FINDINGS ARE THEN PRESENTED IN THE FORM OF AN

INFO GRAPHIC. I HAVE SELECTED THE APPLICATIONS OF BIM IN PROJECT MANAGEMENT FOR MY STUDY FOCUS & HAVE CREATED A COMPREHENSIVE INFO GRAPHIC COVERING TOPICS .

PROJECT 1 -

BUILDING MODELLING

*KINDLY CLICK THE TITLE 'PROJECT 2A - BIM MODELLING' FOR THE PROJECT' 2A'S BRIEF

BIMBUILDINGINFORMATIONMODELLING

PROJECT 2A -

1. Setting Up Levels

2. Setting Up Grids

3. Drawing Floor Plate and Walls

4. Editing Wall Properties

5. Loading and Adding Doors

6. Setting Boundary For Structural Beam Systems

7. Setting Fixed Spacing For Structural System

8. Use Sweep To Create Timber Beam

9. Load in Timber Roof Beams

10. Align Timber Beams with Reference Lines

11. Drawing Roof Profile Boundary

12. Selecting Floor Type

13. Loading In Fixtures and Furniture

14. Creating Double Swing Door Family

15. Constrain Extrusion Depth To Reference Plane

16. Testing Constraints

17. Creating Void Extrusions

18. Inspecting Double Swing Glass Door

19. Load Door Into Model

20. Window Panel Family Creation

21. Creating Window Extrusion

22. Adjusting Mullions on Curtain Wall of South Facade

23. Window Inserts for Curtain Wall Family Creation

24. Offset Used To Create Window Frame Extrusion

25.Window Inserts Loaded Into Model

26. Drawing Railings On The Lookout Deck

27. Creating Storefront Curtain Wall On the North Elevation

28. Creating Extrusion for Chimney

29. Cutting Out Gap for Chimney

30. Drawing Staircase

31. Roof And Its Components Are Aligned to The Reference Planes

32. Wall Foundation Created

33. Boundary for Roof Profile of Flat Roof Drawn

34. Flat Roof Base Offset Adjusted

35. C-Channel Drawn Along The Roof

36. Drawing Extrusion of Chimney Pipe

37. Drawing Void Extrusion For Chimney Pipe

38. Drawing Extrusion for Chimney Pipe Cover

39. Topography Was Created Using Toposurface

40. Subregion Is Used To Draw The Road

BUILDING DOCUMENTATION

*KINDLY CLICK THE TITLE 'PROJECT 2B - BUILDING DOCUMENTATION' FOR THE PROJECT' 2B'S BRIEF

THE SECOND PHASE OF THE SECOND PROJECT REQUIRES US TO PRODUCE BUILDING DOCUMENTATION DRAWINGS FROM THE REVIT MODEL CREATED IN MODEL 2A BY USING REVIT DOCUMENTATION COMPONENTS SUCH AS SHEETS, TITLEBLOCKS, SECTIONS, ROOM TAGS, SCHEDULE AND PHASING.
